Factory price 1P/2P/3P/4P DIN Rail MTS Dual Power Manual Transfer Isolating Interlock Circuit Breaker

Short Description:

DZ47-63 dual power interlock switch has two major structural features. First of all, it uses PA flame retardant material, which closes quickly and effectively improves safety. Secondly, this product is mainly used in public places such as home life, business clubs, hotels, shopping malls, etc. to meet the power switching needs in different scenarios. The structure design is reasonable, the functions are diverse, and the application range is wide, providing users with a more convenient and safer use experience.


Product Detail

Product Tags

Technical Data

Type DZ47 series
Product Name Dual power interlock transfer switch
Curve Type C Type
Features Overload/Short Circuit/Isolation protection
Pole 1P,2P,3P,4P
Rated Current 10A,16A,20A,25A,32A,40A,63A
Rated Voltage 230/400V
Isolation Voltage 500V
Breaking Capacity 6000A
Installation Din-Rail

Dual power interlock transfer switch_7【宽7.62cm×高7.62cm】
