Manufacturer Price S-120W Switching Power Supply Transformer for LED Strip Light

Short Description:

The S-100, 120, 150 series is a 100W/120W/150W single-output enclosed power supply featuring an 85-264VAC wide-range AC input.

The entire series provides 5V, 12V, 15V, 24V, 36V, and 48V output options. With an efficiency of up to 91.5%, its metal mesh housing enhances heat dissipation, enabling the S-100/120/150 to operate over a temperature range of -30°C to +70°C without a fan. Ultra-low no-load power consumption ensures end systems can easily meet international energy efficiency requirements. The S-100/120/150 series offers complete protection and 3G vibration resistance, and complies with international safety standards including TUV EN 60950-1, EN 60335-1, EN 61558-1/-2-16, UL 60950-1, and GB 4943. It provides a cost-effective solution for a wide range of industrial applications.

Send email to us

Product Detail

Product Tags

Technical Data

Type		Technical indicators
Output	DC voltage	5V	12V	24V	36V	48V
	Rated current	18A	8.3A	4.1A	2.8A	2.1A
	Rated power	90W	100.8W	100.8W	100.8W	100.8W
	Ripple and noise	＜75mVp-p	＜120mVp-p	＜150mVp-p	＜240mVp-p	＜240mVp-p
	Voltage regulation range	±10%
	Voltage precision	±2.0%	±1.0%
	Linear adjustment rate	±0.5%
	Load rregulation rate	＜±1.5%	＜±0.5%	＜±0.5%	＜±0.5%	＜±0.5%
Input	Voltage range/frequency	180-264VAC 47Hz-63Hz(254VDC~370VDC)
	Efficiency(typcial)	＞75%	＞82%	＞84%	＞84%	＞84%
	Working current/Shock current	＜1.2A 220VAC ; 220VAC 36A
	Start up time	200ms,50ms,20ms;220VAC
Protection characteristics	Over load protection	≥105%-150%;Constant current output +VO falls to the underpressure point, cut off output reset: power up again
	Short circuit protection	+VO drops to underpressure point to close output
Environmental science	Working temperature and humidity	-10ºC~+50ºC;20%~90RH
	Storage temperature and humidity	-20ºC~+85ºC; 10%~95RH
Security	Pressure resistance	Input – output :1.5KVAC input-case :1.5KVAC output -case: 0.5kvac duration :1 minute
	leakage current	Input-output 1.5KVAC<5mA
	leakage current	Input-output 220VAC<1mA
	lnsulation impedance	Input-output and input-shell, output-shell: 500 VDC/100mΩ
Other	Size	1999838mm(LWH)
	Net weight / gross weight	535g/580.8g
Remarks	(1)Measurement of ripple and noise: Using a 12 “twisted-pair line with a capacitor of 0.1uF and 47uF in parallel at the terminal,the measurement is carried out at 20MHz bandwidth.
	(2)Efficiency is tested at the input voltage of 230VAC,rated load and 25ºC ambient temperature.Accuracy: including setting error,linear adjustment rate and load adjustmient rate.Test method of linear adjustment rate: testing from low voltage to high voltage at rated loadLoad adjustment rate test method: from 0%-100% rated load.The start-up time is measured in the cold start state, and the fast frequent switch machine may increase the startup time.When the altitude is above 2000 meters, the operating temperature should be lowered by 5/1000.

What is the difference between regulated power supply and switching power supply?

There are two topologies to consider for this goal, linear regulated and switch mode power supplies. Linear regulated is ideal for applications that require low noise, whereas switching power supplies are better suited for handheld devices where battery life and efficiency is important.
