Made-In-China S-2000W Industrial AC-DC Converter Switching Power Supply Transformer

Short Description:

The S-1500, 2000, 3000 series is a 1500W/2000W/3000W single-output enclosed power supply featuring an 85-264VAC wide-range AC input.

The entire series provides 5V, 12V, 15V, 24V, 36V, and 48V output options. With an efficiency of up to 91.5%, its metal mesh enclosure enhances heat dissipation, ensuring stable operation even in harsh environments. Ultra-low no-load power consumption makes it easy for end systems to meet international energy efficiency requirements. The S-1500/2000/3000 series is equipped with complete protection functions and complies with international safety regulations including EN 60950-1, EN 60335-1, EN 61558-1/-2-16, 60950-1, and GB 4943. It offers a cost-effective solution for a wide range of industrial applications.

Send email to us

Product Detail

Product Tags

Product Parameter

Type		Technical indicators
Output	DC voltage	12V	24V	36V	48V
	Ripple and noise	＜150mVp-p	＜150mVp-p	＜240mVp-p	＜240mVp-p
	Voltage regulation range	±10%
	Voltage precision	±1.0%
	Linear adjustment rate	＜±1%
Input	Voltage range/frequency	180-264VAC 47Hz-63Hz; 254VDC~370VDC
	Shock current	60A 230VAC
	Start up time	200ms,50ms,20ms;220VAC
Protection characteristics	Over load protection	Constant current output +VO falls to the underpressure point, cut off output reset: power up again
	Short circuit protection	RTH3: Fan often turn, ≥90°C Close the output
Environmental science	Working temperature and humidity	-10ºC~+50ºC;20%~90RH
	Storage temperature and humidity	-20ºC~+85ºC; 10%~95RH
Security	Pressure resistance	Input – output :1.5KVAC input-case :1.5KVAC output -case: 0.5kvac duration :1 minute
	leakage current	Input-output 1.5KVAC<6mA
	leakage current	Input-output 220VAC<1.5mA
	lnsulation impedance	Input-output and input-shell, output-shell: 500 VDC/100mΩ
Remarks	(1)Measurement of ripple and noise: Using a 12 “twisted-pair line with a capacitor of 0.1uF and 47uF in parallel at the terminal,the measurement is carried out at 20MHz bandwidth.
	(2)Efficiency is tested at the input voltage of 230VAC,rated load and 25ºC ambient temperature.Accuracy: including setting error,linear adjustment rate and load adjustmient rate.Test method of linear adjustment rate: testing from low voltage to high voltage at rated loadLoad adjustment rate test method: from 0%-100% rated load.The start-up time is measured in the cold start state, and the fast frequent switch machine may increase the startup time.When the altitude is above 2000 meters, the operating temperature should be lowered by 5/1000.

Type	S-2000
Rated current	150A	80A	55.5A	41.6A
Rated power	1800W	1920W	1998W	1996W
Start up time	<±1.2%	<±1%	<±0.5%	<±0.5%
Efficiency (typical)	>85%	>88%	>89%	>90%
Working current	220VAC:18A
Size	25815887mm
Net weight / gross weight	3kg/3.1kg
