Made-In-China ATMS6002 Single Phase Digital Tuya WiFi Smart Energy Meter Timer

Short Description:

Product Detail

Product Tags

Function

1.Program timer, can set 30 On/Off programs one day or per week.
2.Count down time, from 1 Min to 23 hours 59 Mins.
3.If the product is disconnected from the network, the timer retains all programs set up by Mobile App and works according to the set programs.
4.With memory function, When the product contact is in the close state, after the power failure, and then call, the product contacts still keep the close state.
5.Can be share with 20 users by Mobile App.
6.The products can be worked with Amazon Alexa and Google Assistan.
7.With Bluetooth function, when the WIFI signal is disconnected for 5 minutes, you can use the mobile APP to control the on and off of the product through Bluetooth.
8.In the App can display:
Today Ele (KWh),
Current Ele (mA),
Current Power (W),
Current Voltage (V),
Total Ele (KWh)
9.Expense management function.
10.Over current, Low voltage and High voltage protection function.

Technical Data

Contact specification	ATMS6002WM
Contact configuration	1NO(SPST-NO)
Rated current/Maximum peak current	60A/250VAC(COSφ=1)
Rated voltage/Maximum switching voltage	230V AC
Rated load AC1	13000 VA
Rated load AC15 (230 VAC)	2700 VA
Nominal lamp rating: 230V incandescent/halogen	10000W
Fluorescent tubes with electronic ballast	5000W
Fluorescent tubes with electromechanical ballast	3600W
CFL	2200W
230V LED	2200W
LV halogen or LED with electronic ballast	2200W
LV halogen or LED with electromechanical ballast	5000W
Minimum switching load mW(V/mA)	1000(10/10)
Supply specification
Nominal voltage (UN)	100-240V AC(50/60Hz)
Rated power	3VA/1.2W
Operating range AC(50 Hz)	(0.8…1.1)UN
Technical data
Electrical life at rated load in AC1 cycles	1×10^5
WiFi Frequency	2.4GHz
Ambient temperature range	-20°C~+60°C
