Made-In-China 24V RS485 Signal Surge protective device SPD DIN Rail Arrester

Short Description:

CJ10 series surge protector is in series in front of protected equipment, mainly used in communication lines, telemetry signals, remote control signals, lightning protection for measuring and controlling system etc. Signal equipment protection.Such as the field bus, input/output interface of the 0-20mA, 4-20mA control line. (CJ10 could also be used for telephone line,ADSL/ISDN line). It can suppress induced over-voltage on the signal lines and protect equipment from hazards lightning induction.

Send email to us

Product Detail

Product Tags

Main Character

1. Composed by two parts: the base and the protection module.
2. The signal will not be disconnected when replacing the module.
3. High discharge capacity, low voltage protection level.
4. Protect a pair of signal lines.

Technical Data

Model	CJ10
Rated working votage Un	5V	12V	24V	48V	60V	110
Maximum Continuous Operating Voltage Uc	6V	15V	30V	60V	75V	170V
Rated working current lL	500mA
Nominal Discharge Current (8/20µs)	5kA
Maximum Discharge Current (8/20µs)	10kA
Lightning discharge current (10/350µs)	5kA
Voltage Protection Level Up	≤30V	≤60V	≤80V	≤160V	≤200V	≤600V
Transmission rate	10Mbps
Insert loss	≤0.2dB
Cross-sectional area	Max.2.5mm² flexible
Mounting on	35mm DlN rail
Protection degree	IP20
Working temperature T	-40~+85℃
Relative humidity	≤95%(25°C)
Enclosure material	Gray/Yellow thermoplastic,
