China Supplier 1P+N 32A 6kA MCB Overload Protection Electrical Miniature Circuit Breaker

1.The state-of-art design.
1.1Elegant appearance; cover and handle in arc shape make comfortable operation.
1.2Contact position indicating window.
1.3Transparent cover designed to carry a label.
2.Handle the central-staying function for circuit fault indicating.
2.1In case of overload to the protected circuit, the MCB handles trips and stays at the central position, which enables a quick solution to the faulty line.
2.2The handle cannot stay in such position when operated manually.
3.Handle padlock device.
3.1The MCB handle can be locked either at the “ON” position or at the “OFF” position to prevent unwanted operation of the product.
