Best price MS 15W 35W Single Output SMPS Variable Output Switching Power Supply Transformer

Short Description:

The MS-15, 25, 35 series is a 15W/25W/35W single-output enclosed power supply with an 85-264VAC wide-range AC input.

The entire series provides 5V, 12V, 15V, 24V, 36V, and 48V output options. In addition to an efficiency of up to 91.5%, the metal mesh enclosure is designed to enhance heat dissipation, allowing the MS-15/25/35 to operate over a temperature range of -30°C to +70°C without a fan. Ultra-low no-load power consumption enables end systems to easily meet international energy efficiency requirements. The MS-15/25/35 series features complete protection and 3G vibration resistance, and complies with international safety standards including EN 60950-1, EN 60335-1, EN 61558-1/-2-16, and GB 4943. It offers a cost-effective solution for a wide range of industrial applications.

Send email to us

Product Detail

Product Tags

Technical Data

Type		Technical indicators
Output	DC voltage	5V	12V	24V	36V	48V
	Rated current	2A	1.25A	0.62A	0.42A	0.31A
	Rated power	10W	15.6W	16.8W	15.12W	14.88W
	Ripple and noise	50mVp-p	120mVp-p	150mVp-p	240mVp-p	240mVp-p
	Voltage regulation range	±10%
	Voltage precision	±2.0%	±1.0%
	Linear adjustment rate	±0.5%
	Load rregulation rate	±1.5%	±0.5%	±0.5%	±0.5%	±0.5%
Input	Voltage range/frequency	85-264VAC 47Hz-63Hz(120VDC~370VDC)
	Efficiency(typcial)	78%	82%	84%	84.00%	84%
	Working current	＜0.3A 100VAC ＜0.15A 220VAC
	Shock current	110VAC 18A, 220VAC 36A
	Start up time	200ms,50ms,20ms;220VAC
Protection characteristics	Over load protection	Constant current output +VO falls to the underpressure point, cut off output reset: power up again
	Short circuit protection	+VO drops to underpressure point to close output
Environmental science	Working temperature and humidity	-10ºC~+50ºC;20%~90RH
	Storage temperature and humidity	-20ºC~+85ºC; 10%~95RH
Security	Pressure resistance	Input – output :1.5KVAC input-case :1.5KVAC output -case: 0.5kvac duration :1 minute
	leakage current	Input-output 1.5KVAC<5mA
	leakage current	Input-output 220VAC<1mA
	lnsulation impedance	Input-output and input-shell, output-shell: 500 VDC/100mΩ
Other	Size	876037mm(LWH)
	Net weight / gross weight	150g/175g
Remarks	(1)Measurement of ripple and noise: Using a 12 “twisted-pair line with a capacitor of 0.1uF and 47uF in parallel at the terminal,the measurement is carried out at 20MHz bandwidth.
	(2)Efficiency is tested at the input voltage of 230VAC,rated load and 25ºC ambient temperature.Accuracy: including setting error,linear adjustment rate and load adjustmient rate.Test method of linear adjustment rate: testing from low voltage to high voltage at rated loadLoad adjustment rate test method: from 0%-100% rated load.The start-up time is measured in the cold start state, and the fast frequent switch machine may increase the startup time.When the altitude is above 2000 meters, the operating temperature should be lowered by 5/1000.
